1 Channel 5V Relay Module
This is 1 Channel 5V Relay Board Module For Arduino PIC AVR ESP ARM. A wide range of micro-controllers such as Arduino, AVR, PIC, ARM and so on can control it.
Each one needs 15mA – 20mA driver current and Equipped with high current relay: DC 5V / 10A, AC 250V / 10A
Standard interface that can be compatible with micro-controller.
SKU: EKD003 -
Development
3 Wire Voltmeter 0.36 Inch 4.5V-30V DC Digital Voltmeter Module Board
Product Details:
Display Type Three 0.36 inch LED digital tube Display color Red / Green / Blue Accuracy 1%(+/- 1 Digit) Measuring Range DC0-30V Refresh rate about 200mS / times Power Supply voltage DC 4.5-30V Operating temperature -10 ~ +80 degree This voltmeter uses 0.36 inch LED digital tube without casing. The voltmeter is super thin with small shape and low price and stable performances. It can display well. This voltmeter’s measurement range is wide, it’s DC0-100V. It need outer working power supply and the voltage is DC4.5-30V. There is protection when the wires aren’t correctly connected. This voltmeter’s display resolution is 0.1V.
SKU: DM04 -
Development
DC-DC 12v to 3.3V 5V Module Board
Product Details:
Input Voltage 6 to 12 V Usage/Application Industrial Output Voltage 3.3V and 5V Size 33.7 mm x 30 x 14.4 mm Connector 5.5 mm Power Jack Error Voltage 0.05 V Specification/Additional Details
- Input Voltage6 to 12 V
- Usage/ApplicationIndustrial
- Output Voltage3.3V and 5V
- Connector5.5 mm Power Jack
- Error Voltage0.05 V
Additional Information:
- Item Code: DC-12v-3.3v_5v_TTL
SKU: EK250301 -
Development
I2C Module For 16X2 (1602)
Product Details:
Mounting Solderable pins for direct attachment to the LCD module Supply Voltage (VCC) 5V I2C Address Default: 0x27 (adjustable to 0x20-0x27 with solder jumpers on the PCB) Compatible Displays Works with standard HD44780 controllers (16×2 or 20×4 LCDs) Current Consumption Approximately 20mA (varies based on LCD backlight usage) Chip Used PCF8574T or PCF8574AT Clock Speed Up to 100kHz (standard I2C protocol) Potentiometer Built-in for contrast adjustment Interface Type I2C (Inter-Integrated Circuit) SKU: EK250302-1-1-1-1-1 -
Development
XL4015 5A CC CV Lithium Charger DC-DC Step Down Module Board
Product Details:
Input Voltage 8V to 36V Storage Temperature -65 to 150 Deg C Operating Temperature -40 to 125 Deg C Minimum Drop Out 0.3 V Output Adjustable Voltage 1.25V to 32V Maximum Duty Cycle 100 This product is a 180 KHz fixed frequency PWM buck (step-down) DC/DC module,capable of driving a 0-5A (Max) Adjustable load with high efficiency,
low ripple and excellent line and load regulation. Use as a step-down modules with overcurrent protection capabilities
The DC/DC buck module has applications where the input voltage is higher than the output voltage , such as battery, power transformer, DIY adjustable regulated power supply, LCD Monitor and LCD TVportable instrument power supply telecom/networking equipment,24V vehicle notebook power supply,industrial equipment buck. 12V buck to 3.3V, 12V buck to 5V, 24V buck to 5V,24V buck to 12V, 36V buck to 24V etc.Applications:
- Use as a step-down modules with overcurrent protection capabilities
Usage:- Adjust the voltage potentiometerso that the output voltage reaches the value you want.
- Use a multimeter to measure the output short-circuit current with 10A stalls, while regulating the current potentiometer so that the output current reaches a predetermined overcurrent protection value. (For example, the meter displays the current value of 4A, then you can use the module to a maximum current of 4A)
- Connect the load.
Use as a battery charger
Usage:
- Make sure you need to charge the battery float voltage and charging current; (if lithium parameters 3.7V/2200mAh, then the float voltage is 4.2V, the maximum charging current 1C, ie 2200mA)
- Under no-load conditions, adjust the Voltage potentiometer so that the output voltage reaches the float voltage; (if to 3.7V rechargeable lithium battery, the output voltage can be adjusted to 4.2V)
- Use a multimeter to measure the output short-circuit current, while regulating the current potentiometer so that the output current reaches a predetermined Charging current value.
- Factory default is 0.1 times the charging current; (during charging,current is gradually reduced, if the charge current setting is 1A, then when the charge current is less than 0.1A, blue lights turned off, the green light is on, which means that the battery is fully charged)
- Connected to the battery charge. (1,2,3,4 steps as: Output is unloaded, do not connect the battery)
3.Use as a LED constant current driver module
Usage:
- Adjust the voltage potentiometer so that the output voltage reaches the value you want.
- Use a multimeter to measure the output short-circuit current, while regulating the current potentiometer so that the output current reaches a predetermined LED operating current.
- Connect LED, work. (1,2 steps as: Output is unloaded, do not connect LED)
SKU: EK250302-1 -
Development
XL4015 5A DC-DC Step Down Adjustable Power Supply Buck Module Board with Heatsink
Product Details:
Output Voltage 1.25 to 36 V DC adjustable Input Voltage 4 to 38V DC (Noteinput voltage not exceeding 38V) Dimensions 5.4 x 2.3 x 1.5 cm Output current 0-5A Output power 75W High Efficiency up to 96% This product is a 180 KHz fixed frequency PWM buck (step-down) DC/DC module,capable of driving a 5A load with high efficiency, low ripple and excellent line and load regulation.
The DC/DC buck module has applications where the input voltage is higher than the output voltage , such as battery, power transformer, DIY adjustable regulated power supply, LCD Monitor and LCD TV portable instrument power supplytelecom/networking equipment,24V vehicle notebook power supply,industrial equipment buck. 12V buck to 3.3V, 12V buck to 5V, 24V buck to 5V,24V buck to 12V, 36V buck to 24V etc.
Specifications:- Built in thermal shutdown function
- Built in current limit function
- Built in output short protection function
- Input reverse polarity protection: None (if required,you can attach high current diode in series with the input).
SKU: EK250302 -
Development
XL6009 DC-DC Adjustable Step UP Boost Converter Module Board
Product Details:
Input Voltage 8V to 36V Storage Temperature -65 to 150 Deg C Operating Temperature -40 to 125 Deg C Minimum Drop Out 0.3 V Output Adjustable Voltage 1.25V to 32V Maximum Duty Cycle 100 This product is a 180 KHz fixed frequency PWM buck (step-down) DC/DC module,capable of driving a 0-5A (Max) Adjustable load with high efficiency,
low ripple and excellent line and load regulation. Use as a step-down modules with overcurrent protection capabilities
The DC/DC buck module has applications where the input voltage is higher than the output voltage , such as battery, power transformer, DIY adjustable regulated power supply, LCD Monitor and LCD TVportable instrument power supply telecom/networking equipment,24V vehicle notebook power supply,industrial equipment buck. 12V buck to 3.3V, 12V buck to 5V, 24V buck to 5V,24V buck to 12V, 36V buck to 24V etc.Applications:
- Use as a step-down modules with overcurrent protection capabilities
Usage:- Adjust the voltage potentiometerso that the output voltage reaches the value you want.
- Use a multimeter to measure the output short-circuit current with 10A stalls, while regulating the current potentiometer so that the output current reaches a predetermined overcurrent protection value. (For example, the meter displays the current value of 4A, then you can use the module to a maximum current of 4A)
- Connect the load.
Use as a battery charger
Usage:
- Make sure you need to charge the battery float voltage and charging current; (if lithium parameters 3.7V/2200mAh, then the float voltage is 4.2V, the maximum charging current 1C, ie 2200mA)
- Under no-load conditions, adjust the Voltage potentiometer so that the output voltage reaches the float voltage; (if to 3.7V rechargeable lithium battery, the output voltage can be adjusted to 4.2V)
- Use a multimeter to measure the output short-circuit current, while regulating the current potentiometer so that the output current reaches a predetermined Charging current value.
- Factory default is 0.1 times the charging current; (during charging,current is gradually reduced, if the charge current setting is 1A, then when the charge current is less than 0.1A, blue lights turned off, the green light is on, which means that the battery is fully charged)
- Connected to the battery charge. (1,2,3,4 steps as: Output is unloaded, do not connect the battery)
3.Use as a LED constant current driver module
Usage:
- Adjust the voltage potentiometer so that the output voltage reaches the value you want.
- Use a multimeter to measure the output short-circuit current, while regulating the current potentiometer so that the output current reaches a predetermined LED operating current.
- Connect LED, work. (1,2 steps as: Output is unloaded, do not connect LED)
SKU: EK250302-1-1
